The precise internal diameter of a bore is often one of the most critical features of a machined part, ensuring the proper fit for bearings, seals, and other mating components. Our set of Mitutoyo digital bore gages provides the high-precision measurement required to verify these essential features. This specialized tool allows our technicians to go beyond a simple diameter check, enabling them to analyze the roundness, taper, and cylindricity of a bore with exceptional accuracy.

Key Features and Specifications:

• Type: Digital Dial Bore Gage System

• Brand: Mitutoyo

• Measuring Range: 0.5 inches to 4.4 inches

• Primary Function: High-precision measurement of internal diameters and bore geometry.

• High-Precision Bore Measurement: Specifically designed for measuring inside diameters, these gages provide a level of accuracy and repeatability that is far superior to calipers, which is critical for tight-tolerance features.

• Verification of Critical Geometry: This instrument allows us to accurately measure for any taper or out-of-round conditions within a bore, ensuring that components like hydraulic cylinders or bearing housings are perfectly straight and cylindrical.

• Clear Digital Readout: The easy-to-read digital display provides quick, unambiguous measurements, eliminating interpretation errors and allowing for rapid and confident quality checks.

• Versatile Measuring Range: With a range covering diameters from 0.5" up to 4.4", this set provides the flexibility to inspect a vast majority of the common bore sizes we manufacture.

• Essential for In-Process Control: Our machinists use these gages for in-process checks directly at the machine, allowing them to precisely control boring operations and ensure every part is machined correctly from the start.
