For detailed visual analysis where the smallest details matter, our Flex-Bar Opti-Flex system is an essential tool. This versatile video microscope combines a high-magnification lens with a flexible, articulating arm, allowing us to inspect large or awkwardly shaped components that cannot fit under a traditional microscope. Paired with powerful 2D imaging software, it is a critical part of our quality process for verifying surface finishes, confirming the quality of deburring, and providing clear visual documentation of our workmanship.

Key Features and Specifications:

• Type: Flexible Arm Video Optical Inspection System

• Model: Flex-Bar Opti-Flex

• Software: 2D Workshop Measurement Software

• Primary Function: High-magnification visual inspection and 2D measurement

• Versatile & Flexible Inspection: The articulating flex-arm design provides exceptional reach and maneuverability, allowing us to perform high-magnification inspection anywhere on a part's surface, regardless of its size or geometry.

• Software-Assisted Measurement: Using the integrated 2D Workshop Software, our technicians can perform precise on-screen measurements of small features like radii, chamfers, and angles directly on the live video feed.

• High-Resolution Digital Imaging: The system captures crystal-clear, high-resolution images and video of critical features. This provides indisputable visual proof for our inspection reports and allows for detailed documentation of a part's condition.

• Detection of Microscopic Imperfections: High magnification is crucial for identifying minute defects such as micro-burrs, surface scratches, or cosmetic flaws that are invisible to the naked eye but critical to a part's performance and appearance.

• Ergonomic and Collaborative Viewing: By displaying the image on a large monitor, the system eliminates operator eye strain and allows multiple team members to view and discuss a feature simultaneously, fostering a collaborative approach to quality control.
